Frameless dc coolingfan , Brushless axial DC fan , Mini DC fan
* Bearings: Ball/Sleeve/Hydraulic Bearing
* Premium Environmental and fire prevention PBT UL94V-0 Material.
* Full Certification included CE/UL/TUV.
* Customizable Wire and Connectors
* Customizable Function for Motor protection(RP/SS/LP/CL),Signal output(FG/RD/RDB/LD),Speed control mode(PWM/TC/VC/CC/CS).
Download
3D Model
SHARE:
Product details:
| Size: 70*70*15mm Series
| Voltage: DC 5V-24V
| Current: 0.04-0.5 Amp
| Speed: 2000-3000rpm
| Airflow: 6.82-10.23CFM
| Air Pressure: 1.85-4.15mmH2O
| Total Noise: 27.7-35.6dBA
| MODEL | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Noise | Download Specifications | ||
| PART NO. | VDC | VDC | Amp | Watt | R.P.M | m3/min | CFM | mmH2O | INH2O | DB-A | |
| YY7015L05 | 5 | 3.6to6.8 | 0.20 | 1.00 | 2000 | 0.19 | 6.82 | 1.85 | 0.07 | 27.7 | |
| YY7015L12 | 12 | 8.0to13.5 | 0.10 | 1.20 | |||||||
| YY7015L24 | 24 | 18to26.5 | 0.04 | 0.96 | |||||||
| YY7015M05 | 5 | 3.6to6.8 | 0.30 | 1.50 | 2500 | 0.24 | 8.53 | 2.88 | 0.11 | 32.5 | |
| YY7015M12 | 12 | 8.0to13.5 | 0.15 | 1.80 | |||||||
| YY7015M24 | 24 | 18to26.5 | 0.07 | 1.68 | |||||||
| YY7015H05 | 5 | 3.6to6.8 | 0.50 | 3.00 | 3000 | 0.29 | 10.23 | 4.15 | 0.16 | 35.6 | |
| YY7015H12 | 12 | 8.0to13.5 | 0.25 | 3.00 | |||||||
| YY7015H24 | 24 | 18to26.5 | 0.12 | 2.88 | |||||||
