Frameless dc coolingfan , Brushless axial DC fan , Mini DC fan
* Bearings: Ball/Sleeve/Hydraulic Bearing
* Premium Environmental and fire prevention PBT UL94V-0 Material.
* Full Certification included CE/UL/TUV.
* Customizable Wire and Connectors
* Customizable Function for Motor protection(RP/SS/LP/CL),Signal output(FG/RD/RDB/LD),Speed control mode(PWM/TC/VC/CC/CS).
Download
3D Model
SHARE:
Product details:
| Size: 90*90*10mm Series
| Voltage: DC 5V-24V
| Current: 0.02-0.38 Amp
| Speed: 1500-3500rpm
| Airflow: 15.65-36.21CFM
| Air Pressure: 1.25-2.86mmH2O
| Total Noise: 22.3-37.8dBA
| MODEL | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Noise | Download Specifications | ||
| PART NO. | VDC | VDC | Amp | Watt | R.P.M | m3/min | CFM | mmH2O | INH2O | DB-A | |
| YY9010L05 | 5 | 3.6to6.8 | 0.08 | 0.40 | 1500 | 0.44 | 15.65 | 1.25 | 0.05 | 22.3 | |
| YY9010L12 | 12 | 7.0to13.5 | 0.03 | 0.36 | |||||||
| YY9010L24 | 24 | 18to26.5 | 0.02 | 0.48 | |||||||
| YY9010M05 | 5 | 3.6to6.8 | 0.16 | 0.80 | 2000 | 0.59 | 20.75 | 1.63 | 0.06 | 25.8 | |
| YY9010M12 | 12 | 7.0to13.5 | 0.07 | 0.84 | |||||||
| YY9010M24 | 24 | 18to26.5 | 0.03 | 0.72 | |||||||
| YY9010H05 | 5 | 3.6to6.8 | 0.26 | 1 30 | 2500 | 0.73 | 25.94 | 2.03 | 0.08 | 30.6 | |
| YY9010H12 | 12 | 7.0to13.5 | 0.11 | 1.32 | |||||||
| YY9010H24 | 24 | 18to26.5 | 0.05 | 1.20 | |||||||
| YY9010H05-HH | 5 | 3.6to6.8 | 0.38 | 1.90 | 3000 | 0.89 | 3132 | 2.45 | 0.10 | 33.9 | |
| YY9010H12-HH | 12 | 7.0to13.5 | 0.16 | 1.92 | |||||||
| YY9010H24-HH | 24 | 18to26.5 | 0.08 | 1.92 | |||||||
| YY9010H12-VH | 12 | 7.0to13.5 | 0.32 | 3.84 | 3500 | 1.02 | 36.21 | 2.86 | 0.11 | 37.8 | |
| YY9010H24-VH | 24 | 18to26.5 | 0.15 | 3.60 | |||||||
