120x 120 x 38 mm (4.72 x 4.72 x 1.5 in.) | 110/220V AC | Airflow: 85/103 CFM | Noise: 43/49 dBA | Speed:2600/3000RPM±5%
Download
3D Model
SHARE:
**Designed for projects that requires cooling or ventilation; or as a replacement fan for various products.
**Includes a heavy-duty aluminum fan ,Its possible to come with grills.
**CE Certificated with dual-ball bearings has a lifespan of 50,000 hours. Can be mounted in any direction.
**High Speed: This model is designed to maximize airflow for best cooling on applications.
| Size | Bearing System | Rated Voltage | Freq. | Current | Input Power | Speed | Maximum Air flow | Maximum Air flow | Max.static Pressure | Max.static Pressure | Noise | Mass |
| VAC | Hz | Amp | Waat | R.P.M | CFM | M/MIN | INCHH2O | Pa | DB-A | g | ||
| 120*120*38-A1 | B/S | 115 | 50/60 | 0.28/0.21 | 25/19 | 2600/3000 | 85/103 | 2.4/2.9 | 0.28/0.34 | 70/85 | 43/49 | 520 |
| 120*120*38-A2 | B/S | 230 | 50/60 | 0.13/0.09 | 17/14 | 2600/3000 | 85/103 | 2.4/2.9 | 0.28/0.34 | 70/85 | 43/49 | 520 |
