Frameless dc coolingfan , Brushless axial DC fan , Mini DC fan
* Bearings: Ball/Sleeve/Hydraulic Bearing
* Premium Environmental and fire prevention PBT UL94V-0 impeller and Frame.
* Full Certification included CE/UL/TUV.
* Customizable Wire and Connectors
* Customizable Function for Motor protection(RP/SS/LP/CL),Signal output(FG/RD/RDB/LD),Speed control mode(PWM/TC/VC/CC/CS).
Download
3D Model
SHARE:
Product details:
| Size: 50*50*10mm Series
| Voltage: DC 5V-24V
| Current: 0.03-0.2 Amp
| Speed: 4000-6500rpm
| Airflow: 8.6-14.23CFM
| Air Pressure: 2.97-5.01mmH2O
| Total Noise: 27-37.5dBA
| MODEL | Rated Voltage | Operating Voltage Range | Rated Current | Rated Input Power | Speed | Maximum Air Flow | Maximum Air Pressure | Noise | Download Specifications | ||
| PART NO. | VDC | VDC | Amp | Watt | R.P.M | m3/min | CFM | mmH2O | INH2O | DB-A | |
| YY5010L05 | 5 | 3.6to6.8 | 0.15 | 0.75 | 4000 | 0.24 | 8.60 | 2.97 | 0.12 | 27 | |
| YY5010L12 | 12 | 7.0to13.5 | 0.06 | 0.72 | |||||||
| YY5010L24 | 24 | 18to26.5 | 0.03 | 0.72 | |||||||
| YY5010M05 | 5 | 3.6to6.8 | 0.20 | 1.0 | 5000 | 0.32 | 11.45 | 3.33 | 0.13 | 32 | |
| YY5010M12 | 12 | 7.0to13.5 | 0.08 | 0.96 | |||||||
| YY5010M24 | 24 | 18to26.5 | 0.04 | 0.96 | |||||||
| YY5010H12 | 12 | 7.0to13.5 | 0.14 | 1.68 | 6000 | 0.34 | 11.93 | 4.50 | 0.18 | 36 | |
| YY5010H24 | 24 | 18to26.5 | 0.07 | 1.68 | |||||||
| YY5010H12-HH | 12 | 7.0to13.5 | 0.20 | 2.4 | 6500 | 0.40 | 14.23 | 5.01 | 0.20 | 37.5 | |
| YY5010H24-HH | 24 | 18to26.5 | 0.10 | 2.4 | |||||||
