92x 92 x 38 mm (3.62 x 3.62 x 1.5 in.) | 110/220V AC | Airflow: 39/46 CFM | Noise: 34/38 dBA | Speed: 2700 RPM
Download
3D Model
SHARE:
**Designed for projects that requires cooling or ventilation; or as a replacement fan for various products.
**Includes a heavy-duty aluminum fan ,Its possible to come with grills.
**CE Certificated with dual-ball bearings has a lifespan of 50,000 hours. Can be mounted in any direction.
**High Speed: This model is designed to maximize airflow for best cooling on applications.
| Size | Bearing System | Rated Voltage | Freq. | Current | Input Power | Speed | Maximum Air flow | Maximum Air flow | Max.static Pressure | Max.static Pressure | Noise | Mass |
| VAC | Hz | Amp | Waat | R.P.M | CFM | M3/MIN | INCHH2O | Pa | DB-A | g | ||
| 92*92*38-A1 | B/S | 115 | 50/60 | 0.15/0.11 | 11/8.0 | 2300/2700 | 39/46 | 1.1/1.3 | 0.21/0.29 | 52/72 | 34/38 | 350 |
| 92*92*38-A2 | B/S | 230 | 50/60 | 0.07/0.06 | 11/8.0 | 2300/2700 | 39/46 | 1.1/1.3 | 0.21/0.29 | 52/72 | 34/38 | 350 |
Link: Rubber 3D print
